Baholar:GR.A, GR.B, X42, X46, X52, X56, X60, X65, X70
O'lchamlari:
Tashqi diametr diapazoni: 1/2 "dan 2", 3", 4", 6", 8", 10", 12" gacha
Qalinlik jadvali: SCH 10, SCH20, SCH40, SCH STD, SCH80
Mahsulot spetsifikatsiyasi darajasi (PSL):
- PSL1: Standart ilovalar uchun asosiy talablar.
- PSL2 dan asosiy farqlari:
- Kimyoviy tarkib nazorati kamroq.
- Charpy V-ta'sirini majburiy sinovdan o'tkazilmaydi (agar belgilanmagan bo'lsa, ixtiyoriy).
- Payvandlash uchun maksimal uglerod ekvivalenti (CE) chegaralari past.
- Umumiy, nordon boʻlmagan{1}}xizmat muhitlari uchun ruxsat etiladi.
Ishlab chiqarish jarayonlari:
- Uzluksiz: issiq{1}}o‘ralgan yoki sovuq{2}}chizilgan.
- Payvandlash: Elektr qarshilik payvandlangan (ERW) yoki suv ostida payvandlangan (SAW).
Sinov talablari (PSL1):
- Gidrostatik sinov: Majburiy (devor qalinligi va diametri asosida sinov bosimi).
--Buzuvchisiz sinov (NDT): Payvandlangan quvurlardagi payvand choklari uchun talab qilinadi.
- Ixtiyoriy sinovlar: zarba sinovi, qattiqlik yoki egilish sinovlari (agar xaridor tomonidan belgilab qo'yilgan bo'lsa).
Ilovalar:
- Quruqlikdagi neft/gaz uzatish quvurlari.
- Suv quyish liniyalari.
- Past-bosim yig‘uvchi tizimlar.
- Strukturaviy ilovalar (masalan, qoziq).
Asosiy fikrlar:
- Atrof-muhit: Agar qo'shimcha talablar (masalan, NACE MR0175) bajarilmasa, nordon (H₂S muhitlari) uchun mos emas.
- Payvandlash: API 1104 standartlariga rioya qiling; Idoralar tufayli oldindan isitish kerak bo'lishi mumkin.
- Korroziyadan himoya: qoplamalar (masalan, FBE, 3LPE) yoki katodik himoya ko'pincha talab qilinadi.
Kimyoviy tarkibi va mexanik xususiyatlari:
|
Standart |
Baho |
Kimyoviy tarkibi (%) |
Kuchlanish kuchi (min) |
Hosildorlik (min) |
|||
|
C Mn PS |
Mpa |
Mpa |
|||||
|
API 5L PSL1 (SMLS) |
A |
0.22 |
0.90 |
0.030 |
0.030 |
335 |
210 |
|
B |
0.28 |
1.20 |
0.030 |
0.030 |
415 |
245 |
|
|
X42 |
0.28 |
1.30 |
0.030 |
0.030 |
415 |
290 |
|
|
X46 |
0.28 |
1.40 |
0.030 |
0.030 |
435 |
320 |
|
|
X52 |
0.28 |
1. 40 |
0.030 |
0.030 |
460 |
360 |
|
|
X56 |
0.28 |
1.40 |
0.030 |
0.030 |
490 |
390 |
|
|
X60 |
0.28 |
1.40 |
0.030 |
0.030 |
520 |
415 |
|
|
X65 |
0.28 |
1.40 |
0.030 |
0.030 |
535 |
450 |
|
|
X70 |
0.28 |
1.40 |
0.030 |
0.030 |
570 |
485 |
|
|
Standart |
Baho |
Kimyoviy tarkibi (%) |
Mustahkamlik chegarasi |
Hosildorlik kuchi |
|||
|
C Mn PS |
Mpa |
Mpa |
|||||
|
API 5L PSL2 (SMLS) |
B |
0.24 |
1.20 |
0.025 |
0.015 |
415-655 |
245-450 |
|
X42 |
0.24 |
1.30 |
0.025 |
0.015 |
415-655 |
290-495 |
|
|
X46 |
0.24 |
1.40 |
0.025 |
0.015 |
435-655 |
320-525 |
|
|
X52 |
0.24 |
1. 40 |
0.025 |
0.015 |
460-760 |
360-530 |
|
|
X56 |
0.24 |
1. 40 |
0.025 |
0.015 |
490-760 |
390-545 |
|
|
X60 |
0.24 |
1. 40 |
0.025 |
0.015 |
520-760 |
415-565 |
|
|
X65 |
0.24 |
1.40 |
0.025 |
0.015 |
535-760 |
450-600 |
|
|
X70 |
0.24 |
1.40 |
0.025 |
0.015 |
570-760 |
485-635 |
|
|
X80 |
0.24 |
1. 40 |
0.025 |
0.015 |
625-825 |
555-705 |
|
|
|
Sinf |
Baho |
Kimyoviy tahlil (%) |
Mexanik tayanch |
||||
|
C |
Mn |
P |
S |
Kuchlanish kuchi (Mpa) |
Hosildorlik kuchi (Mpa) |
|||
|
API 5L (ERW) |
PSL1 |
B |
0.26 |
1.20 |
0.030 |
0.030 |
415 dan katta yoki unga teng |
245 dan katta yoki teng |
|
X42 |
0.26 |
1.30 |
0.030 |
0.030 |
415 dan katta yoki unga teng |
290 dan katta yoki teng |
||
|
X46 |
0.26 |
1.40 |
0.030 |
0.030 |
435 dan katta yoki teng |
320 dan katta yoki unga teng |
||
|
X52 |
0.26 |
1.40 |
0.030 |
0.030 |
460 dan katta yoki unga teng |
360 dan katta yoki unga teng |
||
|
X56 |
0.26 |
1.40 |
0.030 |
0.030 |
490 dan katta yoki unga teng |
390 dan katta yoki teng |
||
|
X60 |
0.26 |
1.40 |
0.030 |
0.030 |
520 dan katta yoki unga teng |
415 dan katta yoki unga teng |
||
|
X65 |
0.26 |
1.45 |
0.030 |
0.030 |
535 dan katta yoki unga teng |
450 dan katta yoki unga teng |
||
|
X70 |
0.26 |
1.65 |
0.030 |
0.030 |
570 dan katta yoki unga teng |
485 dan katta yoki teng |
||
|
PSL2 |
B |
0.22 |
1.20 |
0.025 |
0.015 |
415-655 |
245-450 |
|
|
X42 |
0.22 |
1.30 |
0.025 |
0.015 |
415-655 |
290-495 |
||
|
X46 |
0.22 |
1.40 |
0.025 |
0.015 |
435-655 |
320-525 |
||
|
X52 |
0.22 |
1.40 |
0.025 |
0.015 |
460-760 |
360-530 |
||
|
X56 |
0.22 |
1.40 |
0.025 |
0.015 |
490-760 |
390-545 |
||
|
X60 |
0.22 |
1.40 |
0.025 |
0.015 |
520-760 |
415-565 |
||
|
X65 |
0.22 |
1.45 |
0.025 |
0.015 |
535-760 |
450-600 |
||
|
X70 |
0.22 |
1.65 |
0.025 |
0.015 |
570-760 |
485-635 |
||
|
X80 |
0.22 |
1.85 |
0.025 |
0.015 |
625-825 |
555-705 |
||
